Features
- Extreme low elongation
- Excellent UV light stabilization
- Highly flexible, easy to handle
Applications
- Mooring lines
- General industrial and commerical fishing rope
- Anchor lines
Due to a technically reinforced construction of high tenacity Superdan and polyester yarns, Defiance™ Superflex has retained its superior strength. When combined with the unique plied yarn cover construction, this composition provides superior abrasion resistance when compared to conventional ropes. This has been verified through frequent and repeated uses in mooring applications.
Tech Specs
- Class II Rope
- 70% Superdan Polypro & 30% Polyester
- Specific Gravity: 0.99
- Elastic Elongation Percentage: At % of breaking strength – 18-20%
- Splicing Procedures Required
– Eye splice – 8-strand/Class II Rope
– End for End splice – 8-strand/Class II Rope
Size Dia. | Size Circ. | Dia. MM | Weight Per 100’/Lbs | Min Break Strength/Lbs |
---|---|---|---|---|
1 | 3 | 24 | 25.0 | 27,600 |
1-1/8 | 3-1/2 | 28 | 34.3 | 36,600 |
1-5/16 | 4 | 32 | 44.4 | 47,000 |
1-1/2 | 4-1/2 | 36 | 55.4 | 58,400 |
1-5/8 | 5 | 40 | 65.6 | 79,100 |
1-3/4 | 5-1/2 | 44 | 78.3 | 93,900 |
2 | 6 | 48 | 98.4 | 109,000 |
2-1/8 | 6-1/2 | 52 | 112.1 | 126,000 |
2-1/4 | 7 | 56 | 133.7 | 145,800 |
2-1/2 | 7-1/2 | 60 | 149.6 | 165,500 |
2-5/8 | 8 | 64 | 168.5 | 185,200 |
2-3/4 | 8-1/2 | 68 | 198.4 | 207,500 |
3 | 9 | 72 | 212.0 | 232,200 |
3-1/4 | 10 | 80 | 260.7 | 281,600 |
3-5/8 | 11 | 88 | 313.8 | 340,900 |
4 | 12 | 96 | 370.8 | 402,600 |
4-1/4 | 13 | 104 | 434.5 | 423,300 |
4-5/8 | 14 | 112 | 503.3 | 487,300 |
5 | 15 | 120 | 567.5 | 557,800 |
