Each with 6 foot eye splice on one end – 3 foot eye splice on other end. Both covered with heavy-duty chafe protection.
| Size Dia. | Size Circ. | Dia. MM | Approx. Weight Lbs | Min Break Lbs | Length Mtr (Ft.) |
|---|---|---|---|---|---|
| 2-1/4 | 7 | 56 | 66 | 140,000 | 11 (36) |
| 2-5/8 | 8 | 64 | 86 | 162,000 | 11 (36) |
| 3 | 9 | 72 | 107 | 200,000 | 11 (36) |
| 3-1/4 | 10 | 80 | 135 | 250,000 | 11 (36) |
| 3-1/2 | 11 | 88 | 159 | 300,000 | 11 (36) |
| 4 | 12 | 96 | 194 | 360,000 | 11 (36) |
